The Delem DAC 360s controller provides a user friendly and versatile solution for shearing machines. Upon demand multiple back gauge axes, cutting angle, stroke length and gap can be controlled, based on state of the art electronics. Next to back gauge control, the DAC-360s automatically calculates the required setting for the cutting angle and gap depending on material properties and thickness. The stroke length is optimized based on the required cutting length, increasing productivity. The back gauge control supports servo control, 2-speed AC control as well as inverter control. Depending on the application you can select either two side positioning or single side positioning with spindle correction.
The DAC-362s supports dual axis control, offering control for an extra back gauge or front gauge and related functionality.
Full force control for clamping and cutting is available in the DAC-360s.
With its tabular navigation on the bright LCD screen a clear and easy operation is offered. The numerical programming is user-friendly and guides the operator through all programming possibilities.
DAC-360s featuring
- Panel based housing
- Bright LCD screen
- Back / front gauge control
- Retract function
- Cutting angle and gap control
- Stroke length limitation
- Manual movement of all axes
- Force control
- Sheet thickness measurement
- RTS, Return to Sender function
- Second servo axis (DAC-362s)
- Sheet support
Product configuration
Standard
- 4.7” monochrome LCD
- Program memory for 100
programs
- Up to 25 steps per program
Ordering information
- DAC-360s, compact shear control
- DAC-362s, dual axes compact shear control
Technical specification
General
- Program library
- Millimetres / inches selection
- Power-down memorisation
- Machine hour counter
- Stroke counter
Axis
- Stroke control
- Gap control
- Angle control
- Back/front gauge control, dual gauge control (DAC-362s)
- Stroke 0 - 9,999.99 mm.
- Retract 0 - 9,999.99 mm.
- Correction -9.99 - 9.99 mm.
- Retract programmable
- Simultaneous axes movement
- Manual movement of axes
Force control
- Clamping force
- Cutting force
Housing
- Panel based, vertical housing
- Dimensions 189 x 257 x 44 mm
Programming functions
- Numerical program setup
- Back gauge position
- Retract function
- Angle programming
- Gap programming
- Stroke length
- Step repetition
- Material types / properties
- Thickness
- Stock counter
- Sheet position
- Axis speed
- Sheet support
- “Return to sender” function
- Sheet thickness measurement
- Back gauge park position
Computed functions
- Angle, gap and stroke length computation
- Force (clamping / cutting)
- Backgauge safety zone
Integrated functions
- Diagnostic mode
- Service mode
